Keyboard :

SV-1-73 Black : 73 keys.

Velocity sensitive Korg RH3 (Real Weighted Hammer Action 3)

Touch selection:

Eight curves

Tuning:

Transpose, Fine tuning, Tuning curves

Sound generation:

EDS (Enhanced Definition Synthesis)

Polyphony:

80 notes (max)

Sounds:

36 sounds (6 banks x 6 variations)

Bank 1 (E. Piano 1): Tine EP/Amp, Tine EP/Phaser, Tremolo EP, Dyno EP, VPM Piano, VPM Tine

Bank 2 (E.Piano 2): Reed EP 1, Reed EP 2, Electric Grand, SG-1D Piano, 80's Synth Piano, MIDI Grand

Bank 3 (Clav): Clav AC, Clav BC, Clav BD, Clav AD, Piano-ette, ElectraPno

Bank 4 (Piano): Grand Piano1, Grand Piano2, Mono Grand, Upright, Piano/Strings, Piano/Pad

Bank 5 (Organ): Tonewheel x 3 (Click, Jazz, Full), Console Organ, Italian Combo, VOX Combo

Bank 6 (Other): Full Strings, Tape Strings, 70s Strings, Choir, Synth Brass, Sharp Brass

Favorites:

8 favorite switches for quick control panel registration

Equalizer:

Bass, Mid, Treble

Pre FX:

Compressor, Boost, U-Vibe, Vibrato, Tremolo, VOX Wah

Amp Models:

Amp 1 / 2 / 3 / 4 / 5 / Organ Amp + Cabinet Models, Valve Reactor Technology - 12AX7 tube

Modulation FX:

Chorus1, Chorus2, Phaser1, Phaser2, Flanger, Rotary

Reverb/Delay:

Room, Plate, Hall, Spring, Tape Echo, Stereo Delay

Total FX:

Stereo Mastering Limiter, Stereo Limiter

Effect Controllers:

Equalizer On/Off - 3 encoders: Bass, Mid, Treble

Pre FX 2 switches:

On/Off, Auto/Pedal switch for Wah

3 encoders:

Type select, Speed, Intensity

Amp Models On/Off - 2 encoders:

Type select, Drive

Modulation FX 2 switches:

On/Off, Rotary Slow/Fast

3 encoders:

Type select, Speed, Intensity

Reverb/Delay 2 switches:

On/Off, Tap Tempo

2 encoders:

Type select, Depth

Other Controls:

4 switches

Panel Switches:

Transpose, Local Off, Touch, Function, Demo = Transpose + Local Off

Volume:

Master Volume Knob

Connections:

Audio output, Audio input, Headphones, MIDI, Computer, Damper

MIDI:

In / Out

Headphones:

1 (on the front panel)

Audio outputs:

L, R (2 x XLR, Balanced)

L/Mono, R (2 x 1/4" Jack, Unbalanced)

Inputs:

L/Mono, R

Computer:

USB Type B connector (doubles the MIDI interface), USB 1.1 Supported

Damper pedal:

Korg DS-2H, supplied

Pedal 1:

Footswitch (like Korg PS-1)

Pedal 2:

 Volume/expression (like Korg XVP-10 or EXP-2) or footswitch (like Korg PS-1)

Demo:

36 x incorporated demos

Power supply:

Internal switching adapter, AC100~240V, 50/60Hz

Power consumption:

15 Watt

Dimensions (W x D x H) :

SV-1-73 Black = 45.0 x 13.66 x 6.1 inch (1143 x 347 x 157 mm) excluding music stand

Weight:

SV-1-73 Black = 38.5 lbs. (17.5 kg)

excluding music stand

Included accessories:

 Power cable, User Guide, Accessory Disk, music stand, damper pedal (Korg DS-2H)

Bonus software:

SV-1 Editor (Windows / Mac)

Optional accessories:

CB-SV1 Carrying Case, ST-SV1-BK Keyboard stand, XVP-10 volume/expression pedal,

XP-2volume/expression pedal, PS-1 footswitch pedal

*Specifications and features are subject to change without notice.
